DVWA 1.9: File Inclusion Medium and High

7:52 AM 5 Comments

Although I've studied and practiced secure coding standards for some time now, I had yet to try my hand at the offensive approach before last Friday when I downloaded DVWA and started working on the exercises.

File Inclusion

The file inclusion exercises were unexpectedly eye opening. Initially, I thought: "Directory traversal, get the etc/passwd file, etc., etc., not much here I don't already know." Then, I stumbled into Ashfaq Ansari's walkthrough of File Inclusion and Log Poisoning on DVWA Low which showed to my astonishment how one could use this security hole to poison logs and subsequently upload a php shell to the DVWA server.

Clever. Not bad for a day's work, right?

Medium Level

Thanks to Mr. Ansari, I learned a lot more than I thought I would about the dangers of file inclusion security holes; however, there was more to come. On the medium level, the same directory traversal attack initially seems defended against with the following code:

$file = str_replace( array("http://", "https://"), "", $file);
$file = str_replace( array("../", "..\""), "", $file);

Now, the url parameter value "../../../../../etc/passwd" will instead be transformed into etc/passwd and nothing will show:

Blacklisting is hard, though, and a single-pass search and replace cannot remove all ills. Consider, for example, what would happen when performing a str_replace on "hthttp://tp://". You, of course, would be left with "http://", the thing you were trying to prevent from being in the string in the first place!

So, of course, if all one is going to do is remove the "../" instances from the string, we simply need to construct a string that will leave "../" instances in the wake of a search and replace, e.g. "....//....//....//....//....//etc/passwd" or "..././..././..././..././..././etc/passwd" will both do fine.

Now, the same steps of log poisoning and shell uploading can again be performed with relative ease.

The right way to defend against this is whitelisting, which the higher levels of this exercise employ.

High Level

Actually, I'm not certain quite how to leverage this, yet, but I thought I'd post some of my initial thoughts. The defense against file inclusion in the high level is incomplete because unintended patterns can get passed it:

if ( !fnmatch("file*", $file) || $file != "include.php" ) {
    echo "ERROR: File not found!";

Here, the regex allows for the file protocol, e.g. page=file:///etc/passwd. Since this would simply serve files from the user's local machine, I'm not sure what could be done with it, but I found it interesting.


A broken CompletableFuture invocation with an unexpected fix

During a recent training, I was demonstrating the class CompletableFuture and how it could be used to create non-blocking methods like this:

    public static void <T> persist(T entity, Consumer<T> andThen) {
        return CompletableFuture.supplyAsync(() -> {
            System.out.println("Persisting entity...");
            return entity;

    public static void main(String[] args) {
        persist("toPersist", System.out::println);

I wrote a method like the one above and ran the application. The output, unfortunately, was only:


Where did the "Persisting entity..." output go?

(P.S.: The absolute worst feeling ever is when you create an example during a training, and it doesn't work! I definitely should have had a precreated example, but that is beside the point. =])

Since it can be hard to think when there are 30 people watching you, I did the first thing that came to mind. I created an ExecutorService and handed that reference into the thread pool. Now the code says:

    private static final ExecutorService pool = Executors.newCachedThreadPool();

    public void <T> persist(T entity, Consumer<T> andThen) {
        return CompletableFuture.supplyAsync(() -> {
            System.out.println("Persisting entity...");
            return entity;
        }, pool).thenAccept(andThen);

And it worked! It was a bit of a shock, but I was pleased that I could fix it and move on to other topics. :)

After class, though, it gnawed at me, and I was excited when I finally got a minute to sit down and poke at it.

After peeling away a couple of layers, I found that I could reproduce the problem in the following way:

public static void main(String[] args) {
    ExecutorService pool = new ForkJoinPool(1); //Executors.newCachedThreadPool();

    pool.execute(() -> System.out.println("Done"));


This example will only print out "Done" occasionally. However, if I change it to:

public static void main(String[] args) {
    ExecutorService pool = Executors.newCachedThreadPool();

    pool.execute(() -> System.out.println("Done"));


It will work every time.

What's going on? Long story short, I posted my Fork/Join vs ThreadPoolExecutor question to Stack Overflow and John Vint gave the simple answer that all threads in the Fork Join pool are Daemon threads, which means that the VM will stop running without waiting for them to complete. The ThreadPoolExecutor creates non-deamon threads which causes the runtime to wait until they are done.

What does this mean for the in-class example I gave? If you need the runtime to hang on while your CompletableFuture is finishing, pass an Executors-obtained thread pool as a second parameter since by default it uses the Fork/Join common pool.


An Advanced Java Readlng List

10:55 PM , 0 Comments

Recently, I finished doing a 32-hour training over 8 days for a group for 30 Java professionals. We covered several topics, and I published to them a list of further reading that has influenced me as a developer over the years. Perhaps you will find value in the same list I shared with them:

  1. Head First Design Patterns - My co-workers and I studied this book a chapter a week together over lunch back in 2007. Decorators, Observers, and Strategies completely changed my perspective on how to develop code prepared for change.

  2. Effective Java (2nd Edition) - After having developed in Java for 14 years, I finally picked up Josh Bloch's book and after the first chapter I was sorry I had waited so long. It explained and validated many of my long held practices as well as introduced me to additional good ones, like the self-documenting power of public static final methods as named constructors.

  3. Java SE8 for Programmers (3rd Edition) (Deitel Developer Series) - Java 8 is the coolest Java release since Java 5. Method references and lambdas immediately changed the way I code for the better. In addition, java.time is the Date/Time API we've always wanted. Deitel's book is great at exposing all the great new features that will change the way you code in Java.

  4. Starting Out with Java: Early Objects (4th Edition) (Gaddis Series) - Alternatively, there were some attendees who wanted a good foundational Java book. I've used this book when teaching intro Java classes, and I like it! Especially, I like the early introduction to object-oriented programming.

  5. Java Concurrency in Practice - This is another eye-opening book that I waited far too long to read. Atomicity I understood, but I had never considered the ideas of visibility or re-ordering. And I was completely helped out by his explanation for what to do with InterruptedException.

  6. Java Performance: The Definitive Guide

  7. Iron-Clad Java: Building Secure Web Applications - I included this one because security is often tacked on after running some vulnerability assessment. While I might agree that one should "optimize after", security should be built in from the start.

  8. Mastering JavaServer Faces 2.2 - To be honest, I prefer an action-based framework like Spring MVC, but JSF 2.2 caught my eye, especially with the new HTML5-friendly JSF attribute syntax. More than that, this group of engineers asked for training on it, and this is a great book to get a more comprehensive view. :)

  9. REST in Practice: Hypermedia and Systems Architecture - This book is not quite as practical as the rest of them, but I really liked the theory outlined here, mixed with code examples. Through this book, I better understood the gaps that exist between existing libraries and what ReST specifies.

  10. Pro JPA 2: Mastering the Java(TM) Persistence API (Expert's Voice in Java Technology)

  11. Java Message Service - This book helped me understand an API that had to that point had seemed so inaccessible to me. That and Spring Boot made it super-easy! :)



Lemon Squash and 20 Minutes of Coding

HTML-encoded Lemon Squash
A couple of weeks ago, I decided I would try an experiment with my two oldest children and my wife sort of similar to the time I planted a Lemon Squash in our backyard:

Have we tried it before? No.
Do we know if we'll like it? No.
Do we know if it will even grow in our climate zone? No.

Sounds like a winner!

So hear goes... having kids learn along with non-coder Mom is like growing lemon squash in the garden:

Lemon Squash is Hearty

We learned very quickly that lemon squash didn't require a lot of maintenance, wasn't vulnerable to squash bugs like all our other squash plants, and basically grew even with us often forgetting to water it. For a family of six kids, that's a big plus. :)

Likewise, having the boys learn HTML using codecademy.com was a very self-directed process. Compared to the logical dead ends that my students at Neumont will run into with if statements and for loops, my boys, in the world of HTML, were relatively impervious to bugs. The closest they got to a head scratcher was the following:

  <h3>Seven Things I Like To Do
  <p>Play the piano</p>
  <p>Read books</p>

(This was made trickier because codecademy said that the solution was correct.) In HTML, all tags must be closed when we are done with them, much like turning off the bathroom light when you are done with it (this analogy worked for my older, more rules-conscious son). When the above is rendered by a browser, all three lines are in bold:

Seven Things I Like To Do
Play the piano
Read books

 Of course, my boys don't know that this was a bad thing and neither does my wife. They didn't know what it is supposed to look like in the end.

However, when my wife checked it over, she noticed the error based on the detailed instructions and explained the concept as she understood it to the boys. The boys fixed the error, and it then looked like this:

Seven Things I Like To Do

Play the piano
Read books

At that point, my wife said "Oh, so that's why it was all bold: The browser thought the paragraphs were part of the header." Bingo!

Small bugs like these quickly became easy for my boys and my wife to squash (see what I did there?) repeatedly until the entire species retreated into extinction.

Further, other than tag issues, my boys needed very little direction from Mom. Without any parental instruction, my younger son began shouting "DOCTYPE!"
at the beginning of each exercise since he knew it was required no matter what, which filled me with the same amount of pride as the first time he recited the "Inigo Montoya" line from the Princess Bride by heart.

In the end, they were able to get through the first 15 exercises with only minimal correction from my wife. I personally never once corrected the kids nor my wife. Sometimes my wife would ask me a theoretical question or two after the kids went to bed, though. (By the way, those conversations where fun. It was the first time that I can remember my wife showing a technical interest in what I do for a living.)

While hearty, the process wasn't perfect. There was some churn around the fact that codecademy would often tell the boys they were right when actually there were some (what I would consider) important syntax bugs in the HTML they produced. Perhaps the software was built to be lenient. That said, my wife caught the issues and was cognitive enough to know the difference between following the instructions and just getting the software to say "correct!".

Lemon Squash requires water, soil, and sunlight just like every other plant

My wife and I, it turns out, didn't really need to know much about photosynthesis to effectively grow good lemon squash. We just needed to do simple, understandable things like plop the plant in soil that gets sun and pour some water on it. Still, those were necessary elements of making it grow.

Likewise, my wife didn't have to have a lot of formal training, be a genius, or do anything more than use the skills she already had to be there for her boys.

You don't need to be a genius to help kids learn to code.
To be truthful, my wife is a smart cookie, so I won't diminish how her university education may have been brought to bear so that she could assist our boys with such ease. The truth is, though, that codecademy did most of the work. They would read and follow the instructions and the software would do an okay job of guiding them when they misunderstood and did the wrong thing. Thereafter, my wife would "water" by checking things over and helping them make the corrections that the software incorrectly skipped over.

The flow that worked the best was to water regularly. Kristi would hang out
You could do this, right?
while the boys completed the exercises, and she would check each exercise the moment the boys finished. This was a bit of an investment in the beginning; however, after the boys understood the start-and-end-tag thing and a little bit about nesting tags, they were on their way. The first couple of times, Kristi did not do this, resolving to check all their work in the end. This ended up taking much longer because mistakes made on the first exercise would perpetuate through the next five or six. This way, they would practice the wrong way for 20 minutes and then need to be retaught by my wife (which required her to go back through each exercise on her own, doubling the time it took to make progress). This created frustration for all three. Once they changed to the more hygienic practice of checking after each one, it only took a minute or two cumulatively; they boys made more progress and Kristi was less frazzled.

Lemon Squash doesn't taste good to everyone

In the end, I was the only one who would eat the Lemon Squash. I never really understood that because I thought they were excellent. Of course, my children "prefer" only that which is suger-laced, so that could be part of it.

I asked my boys what they thought, and they said it was "fun".
<p>I like trains.<p>
They liked putting silly phrases in the header and paragraph tags and making lists of hobbies, TV shows they liked, and actors they found annoying. They liked adding images to the page and linking to their favorite sites.

I asked my wife and she said, "No, I'm just too busy." For her, squeezing out 5 20-minute sessions where she directed the learning environment was tantamount to me asking her to pull all our children from the public school system and prepare them for college by herself. It made me admire her support all the more, but it also helped me to see that not every parent will be able to carve 20 minutes consistently out of their day to sit and code with their child.


I'm interested enough in this that I'm going to try and get a few more non-coder parents to try it out. The coding world is less scary than it used to be and non-coders can teach other non-coders to code using tools like codecademy. Anyone interested?

It was important for an older person with more training on paying attention to detail to be there with my boys to make sure they stayed on target With a small initial investment, they became quickly self-directing for 90% of the time. It would be interesting to see a button like "Have a Live Volunteer Look At Your Code And Give You Tips" on codecademy or some other site so that Mom or Dad can have a bit more flexibility.

There were a couple of times when the software was incapable of noticing that the syntax was incorrect. Software has bugs, and that's okay; a way to still be helpful while bugs are being fixed might be to have an example picture of what the solution ought to look like in the end so students have a visual way to spot check their solution against the instructions.

Twenty minutes a day was good, though I think that it would eventually need to turn into more. The exercises are written to allow someone to learn piecemeal, but as the concepts get trickier and more abstract, it may take an hour or two of practice before a student feels confident in her understanding. This kind of time commitment would likely be when the student really decided to invest himself in non-trivial coding (like going from picture books to chapter books when learning to read).

Non-coder parents should try this out! My wife did it, and so can you!


When Strings Are Not Immutable In Java

Give this code shot and see what happens:

public class MutableStrings {
    private static void toUpperCase(String str) {
        try {
            Field f = String.class.getDeclaredField("value");
            f.set(str, str.toUpperCase().toCharArray());
        } catch ( Exception e ) {
            // yes, I'm eating an exception! (cuz the above turns out to be a *horrible* idea, so why not compound it with another bad practice?)

    public static void main(String... args) {
        final String greeting = "Howdy";

You should get the very unexpected output of:


What just happened??

So, I was having fun the other day with reflection in one of the Java classes I teach at Neumont University. Based on some cool stuff I learned when I got GSSP certified two years ago, I proposed that strings could possibly be mutable if Java was run without the security manager, making setAccessible(true) available. Sounds like it's worth a try:

public final class MutableStrings {
    public static void toUpperCase(String str) {
        try {
            Field f = String.class.getDeclaredField("value");
            f.set(str, str.toUpperCase().toCharArray());
        } catch ( Exception e ) {
            // yes, I'm eating an exception! (cuz the above turns out to be a *horrible* idea, so why not compound it with another bad practice?)

With this handy method, I can now pretend that strings are, indeed mutable.

Instead of

public final class Mainer {
    public void testStringToUpperCase() {
        String greeting = "Hello";
        greeting = greeting.toUpperCase();
        Assert.assertEquals("HELLO", greeting);

Now, I can do

    public void testStringToUpperCase() {
        String greeting = "Hello";
        MutableStrings.toUpperCase(greeting); // notice the lack of assignment on the left
        Assert.assertEquals("HELLO", greeting);

But, WAIT, there's more!

Because Java uses a String pool, two separate references set to identical string literals can point to the same reference, e.g.

    public void testStringPoolEquals() {
        String greeting = "Hello";
        String salutation = "Hello";
        Assert.assertTrue(greeting == salutation);

Because greeting and salutation point to the same reference in memory, if I change the value property in String reflectively, I get the following behavior:

    public void testStringToUpperCaseStringPoolCorruption() {
        String greeting = "Hello";
        String salutation = "Hello";
        Assert.assertEquals("HELLO", greeting); // okay, makes sense
        Assert.assertEquals("HELLO", salutation); // wait... WHAT??

Woah, what just happened?? Why did salutation get changed as well? Well, now we've come full circle: Strings are pooled in memory in Java. When I do "String variableName = string-literal;", it will search the string pool for that string and fashion a reference pointer to that object in memory instead of creating a new one. When we edit the internal value directly, everyone that points to that same object will get the modified value instead.

Less effective...

Obviously, this is a terrible idea. :) Imagine the chaos of something like string comparison failing because someone reflectively changed the underlying char[] array of a string-pooled public static final variable. It also seems like it could be exploited somehow, tricking an application into rendering malicious information to an end user, like in the case where a hacker gets arbitrary code to run on the server.

Still, it's fun to amaze your friends!


"Have You Done Your 20 Minutes of Reading...er...Coding today?"

When I first became a parent, I was filled with the excitement of being able to teach my kid everything that I knew. I'd teach him how to be creative, responsible, curious, empathetic (at least as far as I understood them), but I'd also teach him fun things like the first 314 digits of pi, juggling, basketball, and coding.

Yes, coding. As a software engineer, I never worked a day in my life. I *love* to code. It's fun. I'd do it even if I weren't paid to do it. And actually, now that I'm a teacher full-time, I can make good on that claim. Although the majority of my day is now spent teaching, I still squeeze in time to code, and it is largely for the fun of it.

To my coding friends: Do you remember the thrill that came from the first time you got your computer to do something you programmed it to do, even if it was simple? I personally remember getting my first Pascal book in high school, and I literally could not put it down. One particular memory I still have from my 14-year-old self is sitting in the back seat in the McDonald's drive thru, nose stuck in my Pascal book while my sisters talked about Jonathan Taylor Thomas or some such*.

I wanted my kid to have the same thrilling experience, the same overwhelming passion. I wanted to see the deep focus come over them that comes over me when I have a terribly abstract and difficult problem to reason around and the subsequent exultation when they finally see the light at the end of the tunnel and realize that they did it.**

For me, teaching my kids coding was always a want. I heard about Scratch, and I downloaded it. I learned about Greenfoot and downloaded it. I tried them both on my kids with a mild amount of success. I spent an afternoon with my 8 and 10 year old boys and built an animation where three stick people would run up a ladder, slide down a slide, and fly into the wall, including sound effects that would only attract 8 and 10 year old boys. Another afternoon, we built an LDS missionary app where the missionary had to walk around and visit all the houses before the "bees" caught him. On another day, we built a simple frogger game. Another, we built a "Family Home Evening Spinner". We had fun.

Now, though, I believe I'm transitioning. "I want" is slowly turning into "I should" or "they need".

Reading Coding is Fundamental

I think about coding like I think about reading and writing. Research, studies, and our own intuitions seem to confirm that reading aloud to our children every day enstills within them a skill that will assist them in solving big problems, getting a larger world view, and generally being productive in society. Clearly, not being able to read and write is an enormous disadvantage in this day and age.

In parts of the world where literacy is low, those who are literate are invaluable to their community, often serving in positions of leadership and working at the forefront of the community's biggest problems.

Sound like what coders are doing today? One need only look as far as heavily code-literate institutions like Google to see some of the impressive problems that are now being solved today that were once considered intractable or at least only part of the distant horizon.

As Gabe Newell from Valve put it: "The programmers of tomorrow are the wizards of the future. You're going to look like you have magic powers compared to everybody else."

I'll take that a step further, though. I don't only want my kids to have those "magic powers" in order to make big, positive differences in the world. They are going to need them.

Douglas Rushkoff explained that "When we acquired language, we didn't just learn how to listen, but also how to speak. When we acquired text, we didn't learn just how to read, but how to write. Now that we have computers, we are learning to use them but not how to *program* them."

Largely, the world seems satisfied to allow themselves to become increasingly dependent on "geeks" for increasingly fundamental aspects of their day to day lives. Many not only consider the inner workings of computers and the Internet "unknowable" but even "worthless to know".

However, I believe that such an imbalance between the knows and the know-nots, while convenient in the short term, will put those who don't know how to code at as much of a debilitating disadvantage in the future as not knowing how to read does today. Those who could write centuries ago formed the world in the image they saw as multitudes of non-readers consumed their perception of reality, often independent of its accuracy or precision.

For me, teaching my kids coding was always a want. Now, though, "I want" is turning into "I should" or "they need".

Our children are the consumers of the digital revolution that many of them cannot currently participate it at a production level. Their perceptions even now are being molded by the coders behind Facebook, Google, Instagram, and Twitter. If our youth do not know how to code themselves, they are destined to be relegated to the class of citizens who consume points of view formulated not necessarily by those who are right but by those who are simply more skilled at the lingua franca.

As Patrick Byrne from Overstock once quipped: "Mark Twain once said don't pick a fight with someone who buys ink by the barrel. I say never pick a fight with someone who buys bandwidth by the gigabyte." Kids needed to learn to write. Kids now need to learn to code, too, if they are going to have a say in the makeup of our future world.

"Have Your Done Your 20 Minutes of Coding Today?"

For some of my kids, they love reading so much that they don't need to be reminded. One of my kids reads at the dinner table, in closets, and with a flashlight late into the night. Another reads because it is on her "job chart" and she wants to put down the check mark. A couple of them need to be reminded over and over again if I want to have any kind of output from them.

Regardless, they all know that Mom and Dad expect them to read 20 minutes a day. We read them bedtime stories, we read the Bible and Book of Mormon every night together as a family. They know that Mom and Dad love to read and like to carve out time for our own personal reading during our day.

Kids need daily time coding as well, and it needs to be on the job chart. Or, if that seems too daunting, families can try the rule that we enforce in our house:
When on the computer, be a producer, not a consumer.
My kids are allowed to build stuff in Minecraft, draw pictures in paint, make sound effects and animations in Scratch, learn something new by researching online or anything that basically is not straight up media consumption. We have "Cummings Cash", and I tie that Cummings Cash to certain bounties that are related to them building, creating, and making stuff on or off the computer.

It's time for the Cummings's to level up, though. With our oldest two children (8 and 10), I want them to get familiar with coding more than just as a pastime. So, for one week, I decided to try something new.

The regimen was simple: Work on codeacademy, a codemonkey level, or something coding-related for 20 minutes a day together for one week. I considered the pairing up part to be super-important as my older son is more responsible, but my younger son has more of the "knack". Hopefully together they'd stay on task.

In addition, it's also been on my mind to see whether or not a non-coder parent can help a non-coder kid become more familiar with coding. I imagine that mother or father 300 years ago who had never learned how to write, but now perceived the need for her children to learn to write. What would she do in such a situation to help her children make progress?

So, while not the greatest comparision, I decided that as an additional experiment, I'd ask my wife--a non-coder--to sit in with the boys for those 20 minutes a day. She would follow along with the exercises and help the boys out if they got stuck. We called it the "Code With Your Child" initiative.

To my delight, my wife accepted the challenge! This week, she is working through the exercises with the boys; sometimes she sits and watches, but mostly the boys work on the tasks independently and she verifies after they are done. It's going well! My boys are learning coding from a non-coder! I will post a detailed update when our experiment finishes next week.

In the mean time...

Why don't you give it a shot yourself? IMHO, everyone should know at least a little bit about coding. And maybe pull your kid in with you while you do it.

*Actually, I'm sure my sisters were more sophisticated than that. Kimmie would accept nothing less then Jason Priestly or that one guy from New Kids On The Block.

**My wife tells me that she knows it was a really hard problem when I yell out a "Whoop!" when it finally works.


On Code as the Resume: Two Creative Code-Resumes That Helped Me Get Hired

11:53 AM 0 Comments

Read about five others after you are done here!
A traditional resume is a PDF or doc file with sections like Objective, Work History, and Education neatly organized into columns and sometimes squeezed onto a single sheet of paper for rapid perusal of keywords.

It's important to stand out, though, and as long as you are standing out, why not have a little bit of fun with it?

The two stories that follow are two times where I wrote code as my resume. This isn't a portfolio nor an assigned coding assignment from the interviewer. The code is a resume and the resume is written in code. Hopefully, they will give you some ideas on being creative with the job application process.

XKCD: Meta-Analysis


About 6 years ago, I was applying for an internal position at my company. The team developed tools and libraries for the rest of the 20-30 development teams in the organization which meant that its standards for acceptance were pretty high.

When I became familiar with some of the folks interviewing, I got a little nervous. One definitely had more experience than I.

So, I determined to create a resume that would demonstrate my coding skills in addition to acting as a traditional resume.

Welcome Adam.java. When run in the following manner:

java Adam

It will print out the resume to the console as you might expect.

This is already a little bit nerdy, but not nearly enough to draw their attention. It's probably just enough trouble to annoy the interviewer instead of bump me up the charts.

Welcome Eve.java. Now, run the application in the following manner:

java Adam Eve

And the two will randomly splice a new resume together, creating a new Java file: Adam_Eve.java. It will have taken some of the attributes from the Adam resume and some of the attributes of the Eve resume to make a new, randomly mutated resume that has some of the attributes of each of its precessors.

Now, Adam_Eve can be run:

java Adam_Eve

to see the new resume, OR

java Adam_Eve Eve

to generate a new mutated resume.

I sent the above instructions in my job application as well as the Java files Adam.java, Eve.java, Seth.java, and Carol.java. I stated that they should feel free to splice resumes with each other until they obtain a resume that they like.

The words from one of the devs made my day: "That was the coolest resume we have ever received." Happily, I got the job. :)

I have this code hanging around somewhere, but I made what I thought was a better one later on that was a Mission Statement Generator. You can read about it in the README at its github link: https://github.com/jzheaux/mission-statement-generator. It wouldn't be too difficult to alter mission-statement-generator's code to generate a resume, if you wanted to try it out!


I had a client once who stated that he needed Maven, Spring, Hibernate, Amazon EC2, and JAX-RS experience. He also wanted to see a portfolio. The portfolio was moderately problematic: I don't really have one since nearly all my work over the last 15 years has been backend.

So I decided that there was no time like the present. I turned on my stopwatch and started to build a resume out of Maven, Spring, Hibernate, Amazon EC2, and JAX-RS. Three hours later, I had something simple but that clearly demonstrated that I could build a multi-module project using Spring and Hibernate, deploy it to Amazon EC2, and use CXF (a JAX-RS provider) to create a client and ReSTful server.

You can see the code here:  http://github.com/jzheaux/resume

You can see the resume here: http://resume.joshuacummings.com/resume/100

And you can query the ReSTful API here: http://resume.joshuacummings.com/resume-ws/resume/100

For example:

curl -H  "Accept: application/vnd.joshcummings.com-v1+json" http://resume.joshuacummings.com/resume-ws/resume/100

As you can see, the app doesn't do much other than demonstrate each technologies' "happy path". However, I liked that it was "meta" and, in the end, they hired me so maybe it was worth it.

Should you do this?

In each case above, the situation was somewhat specialized. In the first, it was an internal position, so I knew a couple of the devs that would be looking, and I knew that they were total geeks and would love seeing a resume like that. Also being internal, the volume of resumes was low so I knew they would likely take a minute to actually follow my instructions to run the program.

In the second, I again knew that the application volume was low; further, they had asked for a portfolio, so really I was combining their two requests into one by sending them a product that shared the relevant resume info, demonstrated in the context of a portfolio.

On the other hand, there are several stories of people doing various stunts that both demonstrate their ability to do the job and get them noticed at high profile companies like Google.  Then there are application tactics that are simply memorable, but don't really manifest the applicants abilities.

So, maybe there is some benefit other than the personal satisfaction of "going meta".

What's Next

While more boring, the second one I think is better because it is easy to inspect everything; some non-engineer doesn't need to fiddle with java command-line to see the resume. It also retains the potential for video, audio, and other application-oriented stuff to actually make it a more delightful experience.

Maybe if I ever apply for an Android position, I'll create a resume app with a Mutate button on it. Doesn't that sound like fun?


Neumont Coding Contest 2015 - Qualifying Round Solution

4:06 PM , 0 Comments

Courtesy University of Buffalo

Beware! Solutions follow! First, read the Betsy Ross problem and see if you can come up with your own solution.

Here is one of the submitted solutions to the Betsy Ross problem posted in the previous blog post:

public class BetsyRoss {
 public static void main(String[] args) {
  Scanner input = new Scanner(System.in);
  String line = input.nextLine();
  Integer starCount = Integer.parseInt(line);
  double bestColumnCount = starCount;
  double bestRatio = starCount;
  for ( int n = starCount - 1; n >= 1; n-- ) {
   int remainder = starCount % ( n + ( n - 1 ) );
   if ( remainder == 0 || remainder == n ) {
    double rowCount = starCount / ( n + ( n - 1 ) ) * 2 + (remainder == 0 ? 0 : 1);
    double ratio = Math.max(n, rowCount) / Math.min(n, rowCount);
    if ( ratio < bestRatio ) {
     bestColumnCount = n;
     bestRatio = ratio;


Amongst the fastest-submitted solutions, the most important realization for students was that the odd/even complexity could be reduced by envisioning the rows in odd-even pairs. Either a flag would be comprised of all odd-even pairs (or even-odd pairs) or there would be one odd (or even) row left over.

This means that if one is testing with seven starts on the top row, the flag can be thought of in 13-star groups (7 + 6) with a possible 7 left over. This means that if the total number is evenly divisible by 13 or if it has a remainder of 7 (meaning one additional odd row), then we have a match.

Note that the same principle works if the first row has an even number of stars on the top row. In the case of 8 stars on top, the flag can be though of in 15-star groups (8 + 7) with a possible 8 left over. This means that if the total number is evenly divisible by 15 or if it has a remainder of 8 (meaning one additional row), then we have a match.

Reducing this step of the problem to mere mathematics saves us inner loops that might need to discover the fact empirically, making the solution faster and writable in fewer lines of code.


Another simple construct in problems like this is a max counter. The problem set stated that the number of rows and columns needed to be as close to identical as possible. When looping through experiments, one can keep track of the current best, updating it only when a better one comes along.


Please post below your improvements! The above code runs in under 5 seconds on nine-digit numbers on my machine.


Neumont Coding Contest 2015

10:00 AM , 0 Comments

This year, we decided to hold a coding contest at Neumont University. We did a single-elimination, head-to-head competition roughly similar to the Top Coder Single Round Matches, just with two people in a room instead of 20. We started with 50 entrants, whittled it down to 32, and then, five rounds later, we had our winner!

Because I was in charge of coming up with the problems, I thought I'd post what they were for each round, what some good (and bad?) solutions were, and anything else that comes to mind.

I'll also possibly post a bit on the coding contest server that I built using Spring 4 to teach myself a bit about Java Config.

Qualifying Round

First, the rules: Students could use any IDE and could submit solutions in C# or Java. No Internet, but they could bring in pencil and paper. For the qualifying round, students were given the entire day to solve one problem. Students were be ranked in the order they submitted a correct solution up to 32 submissions.

So, at 10am on February 17th, students were presented with the following problem:

Betsy is interested in flags whose stars are formatted rectangularly where every odd row is the same length and every even row is one star less than the odd rows.

Furthermore, call the width of this flag the number of stars in its first row and the height the number of rows. Betsy prefers the dimensions to be the closest to a square as possible. In the case of a tie, Betsy prefers flags with more columns than rows.

For example, in the case of a 50-star flag,

Betsy likes a flag whose odd rows have 6 stars and whose even rows have 5 stars (resulting in a flag with 9 rows of stars, 6, 5, 6, 5, 6, 5, 6, 5, 6) as opposed to a flag whose odd rows have 5 stars and whose even rows have 4 stars (resulting in a flag with 10 rows of stars). A 6 x 9 flag is closer to a square than a 5 x 10 flag.

For example, in the case of a 46-star flag

Betsy likes a flag whose odd rows have 7 stars and whose even rows have 6 stars (resulting in a flag with 7 rows of stars, 7, 6, 7, 6, 7, 6, 7)
as opposed to a flag whose odd rows have 12 stars and whose even rows have 11 stars (resulting in a flag with 4 rows of stars). A 7 x 7 flag is closer to a square than a 12 x 4 flag.

Create a Solution that reads in the number of total stars from standard in and prints out the number of stars in the first row of Betsy's preferred flag.

Here are some sample inputs and outputs:

50 -> 6
46 -> 7
115 -> 12
112 -> 4
3 -> 2
459384753 -> 28603

The first correct submission was submitted within 40 minutes of the announced problem, and by the end of the day, 29 students were in. How fast can you complete it? I'll post a couple of solutions and my analysis next time.


Three Simple Steps to Convert from EJB 3 to Spring 4

1:46 PM , , 2 Comments

While the merits of doing so are debatable, a client of mine wanted to covert his EJB application into a Maven, Spring, Hibernate application.

His application was small--about 75 classes. The only significant aspects of EJB that he was using was dependency injection and RMI. He did not up to that point have a need for persistence, so there were no existing ties to JPA. He was; however, tied to Jersey 1.x and currently needed a dependency from Netbeans in order to build the product (weird?).

Some of the above may sound similar to your situation. What I'll describe below is how we

1. Migrated the product from Ant to Maven, turning it into a multi-module project.
2. Migrated from EJB to Spring
3. Upgraded from Jersey 1.x to 2.x


As the product stood, it would build an .ear file that exposed a remote interface over RMI and a .jar file that invoked this remote interface. Insofar as we were abandoning EJB for Spring, it would suffice to create a jar file on both sides.

These had a common dependency, which was the shared interface, so I recommended that we create a multi-module maven project which would allow the client and server to both be dependent on an api project. Also, they could all be built with a single command and be automatically related to each other in modern IDEs.

The new project structure

The file structure will change a bit; here is what it will look like in the end:

  -- pom.xml
  -- /api
  ---- pom.xml
  ---- /src
  -- /client
  ---- pom.xml
  ---- /src
  -- /server
  ---- pom.xml
  ---- /src

The master pom

The master pom ties everything together, specifying which and in what order modules should be built:

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"

 <name>Product Parent Pom</name>





The API Project

Then, the API project. For now, this will only contain a single file that needs to be shared between the client and server. In all likelihood, RMI will be abandoned in favor of JAX-RS or Spring MVC down the road, but right now we are changing as little code as humanly possible.

<project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
 xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">


 <name>SDA Api</name>

The API has just one interface and it not annotated with any EJB or Spring annotations; those are placed on the implementations. Because of this, notice that this api has no dependencies, which can come in handy later on if the client wants to use different libraries from the server.

Client and Server

The client and server have several dependencies; I'll try and highlight the important ones:

<project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
 xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/maven-v4_0_0.xsd">


 <name>Product Client</name>

  <!-- API Dependency -->

  <!-- Spring Dependencies -->

  <!-- A particularly important dependency -->

  <!-- Other dependencies not listed -->

Finally, the Server's pom, which I won't post because it is largely the same as the client pom.

The last thing I needed/wanted to do was rearrange the project structure so that it matched Maven's default. This means putting all the source code into src/main/java, all the resources into src/main/resources, and all the JUnit tests into src/test/resources. Pretty simple.

Now, a simple "mvn clean install" from the parent will do all the work!



When in EJB, the interface was exposed via the @Remote EJB annotation. Spring has a nice RMI library, so it was a simple matter of removing the EJB anntotations and providing the correct Spring wiring:


public class AppConfig {
 @Bean(name = "userInterface")
 public RmiProxyFactoryBean remote() {
  RmiProxyFactoryBean b = new RmiProxyFactoryBean();
  return b;


public class AppConfig {
 @Inject UserInterfaceRemote service;
 public RmiServiceExporter rmiServiceExporter() {
  RmiServiceExporter exporter = new RmiServiceExporter();
  return exporter;

So far, no business logic or design changes; just wiring.

Dependency Injection

In EJB, beans can be made eligible for dependency injection via the @Stateless annotation, which was the case here. I replaced these with the appropriate Spring stereotype, e.g. @Service, @Component, etc.

There were a couple of @Stateful annotations (ew) which I could have replaced with the @Scope annotation in Spring. Fortunately, however, the "statefulness" of those beans turned out to be an artifact from a discarded approach, so I replaced those with @Service as well.

On the auto-wiring end, I replaced @EJB with @Inject

And finally, I added the Java Config on both the client and the server to bootstrap Spring:


public class MyWebApplicationInitializer implements WebApplicationInitializer {

 public void onStartup(ServletContext servletContext)
   throws ServletException {
  servletContext.addListener(new ContextLoaderListener(createWebAppContext()));

    private WebApplicationContext createWebAppContext() {
        AnnotationConfigWebApplicationContext appContext = new AnnotationConfigWebApplicationContext();
        return appContext;


public static void main(String[] args) {
     AnnotationConfigApplicationContext context =
             new AnnotationConfigApplicationContext(AppConfig.class);
        ClientUserInterface ui = context.getBean(ClientUserInterface.class);

Excellent, no code changes! To the existing code, we only modified annotations. We added wiring code and maven configurations.


No project goes perfectly, though, and my excitement was tempered by discovering that Jersey's support for Spring 3+ was added in Jersey 2.x. Grrr. Upon attempting to upgrade, by changing the version in the maven pom, there were several places in the code where compilation failed.

The Jersey Migration Guide to the rescue! Especially section 27.16.2, which covered how to change client request from 1.x style to the 2.x style and 27.16.3 where JSON support is explained.

Updating Jersey Client API

I found the Jersey 2.x Client API to be a little confusing when it came to setting headers. Somehow this:

Response response = target.request("text/plain").get();

is setting the Accept header for the request to be "text/plain", which is a change from using the accept() method to set the Accept header.

And how to set the content type for the request? There doesn't appear to be a contentType() method or something similar; it appears to be retreived from the entity sent in the post method:

Response response = target.request("text/plain").post(Entity.entity(payload, "application/xml"));

The typical Jersey Client request appears to be a three-line cocktail of obtaining a Client, deriving a WebTarget via the Client, and then invoking the target to get a Response. In the code I was upgrading, there were several repeated sections of these three lines of code. Grrr! However, at the time I just needed to be surgical about it and not do a bunch of refactoring, so I left the copy-pasta for another day.

JSON Support

Replacing JSON support was super easy: It was simply adding the appropriate jackson-jaxrs-json-provider dependency to maven.

HACK: Ghost applicationContext.xml

There was only one really cheesy thing that I didn't find a good way around. After upgrading to Jersey and following the docs to get Spring and Jersey to play nicely (at least as I understood it to that point), I would always get an exception that said that Spring could not instantiate multiple ContextLoaders. This was really frustrating as I knew that I already had one in my Java config (see above).

By doing some debugging into Jersey, I found this in Jersey's SpringWebApplicationInitializer:

    public void onStartup(ServletContext sc) throws ServletException {
        if (sc.getInitParameter(PAR_NAME_CTX_CONFIG_LOCATION) == null) {
            sc.setInitParameter(PAR_NAME_CTX_CONFIG_LOCATION, "classpath:applicationContext.xml");
        } else {

In short, this is looking to see if there is an applicationContext.xml referenced in the ServletContext already; if not, then create one and add a ContextLoaderListener to the servlet context as well.

The fact is that since I'm using Java config, I don't have an applicationContext.xml! So the first half of the if statement was always running. To get around it, I added a ghost reference to the web.xml file to an empty applicationContext.xml file and it worked like a charm!


Other than one particular library incompatibility, migrating to Maven, Spring 4, Hibernate, and Jersey 2.x was pretty straightforward. Enjoy!
